THREE PHASE INPUT – SINGLE PHASE OUTPUT ONLINE UPS
Description
The DELTRON Three Phase Input, Single Phase Output Online UPS is designed to deliver seamless, clean, and reliable power for critical applications where three-phase input is available but the load requires a stable single-phase output. With capacity ranging from 5 kVA to 40 kVA, this UPS ensures uninterrupted performance for medical equipment, laboratories, industrial control systems, IT infrastructure, and commercial establishments.
Built with advanced DSP-based control algorithms and IGBT technology, the system guarantees pure sine wave output, superior voltage regulation, and high efficiency, even under fluctuating grid conditions.
- True Online Double Conversion Technology – Provides consistent, high-quality power.
- Three Phase Input / Single Phase Output – Efficiently balances input load while delivering stable single-phase output.
- DSP-Based Control – Fast response, precision control, and superior reliability.
- IGBT Rectifier & Inverter – Compact design with high efficiency and low harmonic distortion.
- Wide Input Voltage Range – Handles unstable supply without frequent switching to battery.
- Pure Sine Wave Output – Ideal for sensitive and mission-critical equipment.
- Advanced LCD Display – Shows input/output voltage, load %, battery level, events, and errors.
- Event & Error Log – Stores up to 100 entries for diagnostics and maintenance.
- Intelligent Battery Management – Optimized charging and adjustable settings to extend battery life.
- Comprehensive Protection – Overload, surge, short-circuit, neutral fault, and battery protection.
- Medical & Diagnostic Equipment
- Industrial Control Systems & Machinery
- Data Centers & IT Infrastructure
- Laboratories & Research Facilities
- Banking & Telecom Systems
- Commercial Establishments
- Capacity: 5 KVA, 10 KVA, 12 KVA, 15 KVA, 20 KVA, 25 KVA, 30KVA, 40KVA.
- Input Voltage: 3 Phase, 415V ± 20%
- Input Frequency: 50 Hz ± 5 Hz
- Output Voltage: 230V ± 1% (Single Phase)
- Output Frequency: 50 Hz ± 0.5 Hz (synchronized with mains)
- Power Factor: ≥ 0.9
- Efficiency: Up to 93% (AC-AC)
- THD (Total Harmonic Distortion): ≤ 3% (linear load)
- Crest Factor: 3:1
- Battery: External battery bank, scalable for required backup time
Wide range: 5 kVA to 40 kVA
Perfect for industrial and commercial single-phase loads on a 3-phase supply
Advanced DSP & IGBT technology for maximum efficiency
Comprehensive protection and fault logging
In-house R&D and manufacturing in Kolhapur
Backed by expert service and support
